2 Pcs 15mm 5x120 To 5x114.3 Wheel Hub Centric Spacer Adapters Fit For BMW 3 Series E36 E46
2 Pcs 15mm 5x120 To 5x114.3 Wheel Hub Centric Spacer Adapters Fit For BMW 3 Series E36 E46
SKU:WHS-016-2PCS
Couldn't load pickup availability
Specification
Thickness (Each)：15mm
Vehicle Bolt Pattern：5 x 120 mm
Wheel Bolt Pattern：5 x 114.3 mm
Lip Height：8mm
Stud Hole Diameter：15mm
Centerbore：72.5 mm (Car) To 66.1 mm (Wheel)
Stud/Nut Thread：M12x1.5
Construction：6061 T6 Aluminium Alloy
Outside Diameter：155mm
Included Machine-Pressed Wheel Studs And Matching Lug Nuts
Tips
Bore Depth Varies According To Thickness And Difference Between The Wheel Centre Bore (WCB) And Car Centre Bore (CCB) Sizes
| Spacer Thickness | Bore Depth A | Bore Depth B |
| 15mm | ~12.5mm | 12mm |
| 20mm | ~18mm | 15mm |
| 25mm | ~22mm | 20mm |
| 30mm | ~27mm | 25mm |
| 35mm | ~32mm | 30mm |
| 40mm | ~37mm | 35mm |
| 50mm | ~47mm | 45mm |
Bore Depth A Applies If: -2mm < WBB - CCB < 4mm
Bore Depth B Applies If: WBB - CCB < -2mm
If WCB - CCB > 4mm The Spacer Bore Is Machined The Entire Way Through Without An Internal Supporting Step Required.
Fitment
Fit For BMW 3 E36 46
Package
2 x Wheel Adapters Spacers
| SKU | WHS-016-2PCS |
| Brand | MACHTER AUTOPARTS |
| Shipping Weight | 1.8250kg |
| Shipping Width | 0.180m |
| Shipping Height | 0.110m |
| Shipping Length | 0.195m |
| Shipping Cubic | 0.003861000m3 |
