Enerdrive B-TEC 200Ah Slim Metal Case Lithium Battery

The new 200Ah ePOWER B-TEC Slimline lithium battery is designed and intended for use in deep cycle applications where a single battery is required that meets the amp hour capacity.

• Extremely compact size W 530 x H 600 x D 83 mm. All connection points for the battery are at one end including all Comms Ports and Reset Port.
• Reset button is not included on the battery itself, we have opted for a button that can be remotely mounted elsewhere in the install. This allows for a much easier restart process for customers and also keeps the battery more water tight with less chance of water ingress.
• Comms Ports are both RJ45 remote ports with CAN output. Both are reserved for future integration and functionality.
• Water resistant metal casing meeting IP52 rating and all external bolts and fittings are blind so limits the chance for water to travel from external to internal. Rubber style seals between all metal framing. Frames overlap as well to help avoid water ingress.

Smart Phone Monitoring System: The Enerdrive Enerdrive B-TEC  Slimline battery incorporates wireless Battery Monitoring Technology. By downloading the Android™ or Apple® app to your smartphone or tablet device, you can monitor the following information; Battery Capacity; Battery Voltage; Battery Current (Amps); Battery State of Charge (SOC); Battery State of Health (SOH); Battery Status; Individual Cell Voltage; Battery Temperature; Battery Cycles; Battery Alarms & Battery Event Information.

Battery Management System: The battery is also equipped with an internal Battery Management System that can monitor and optimise each Prismatic cell within the battery during normal operation. It will protect the battery pack from over charge, over discharge, over temperature & short circuit. The BMS helps to ensure safe and accurate operation of the battery.

Size & Weight Savings: Lithium v AGM Capacities; 200Ah Lithium = 320Ah AGM

(Based on standard depth of discharge for both Lithium (80%) and AGM (50%).

The 200Ah Slimline battery is able to accept a maximum inverter capacity of 3000W only. Exceeding the maximum inverter capacity can damage the BMS Management within the battery.

If you are requiring a battery system larger than Enerdrive B-TEC battery, please look at the Enerdrive Pro Series Power Pack Systems which can offer multiple parallel and series connections with Active Cell Balancing Protection across the entire pack.

Please note B-TEC batteries must not be installed –

• In vehicle engine bays or in high heat environments, refer to Section 10 – Battery Specifications of the manual.
• In wet areas such as caravan chassis mounts, open ute trays or boat deck areas.
• Inside compartments dedicated to carrying gas.

SKUEPL-200BT-12V-SLIM

BrandEnerdrive

Product CategoryBatteries

Battery Voltage12V

Amp Hours (ah)200

Battery Length (mm)530

Battery Width (mm)83

Battery Height (mm)600

Battery Weight (kg)30

Cycle Life (DOD – 80% under controlled conditions)≥ 2000 Cycles

Battery Charge Temperature0 ̴ 45°C

Normal Charge Voltage CV/CC14.20 ̴ 14.60V

Standby (Float) Voltage13.50 ̴ 13.80V

Maximum Charge Current150A @ 25°C for 30mins

Battery Discharge Temperature-20 ̴ 60°C

Battery Output Voltage Range11.00 ̴ 14.60V

Maximum Discharge Current250A@25°C ± 5°C for 30mins

Pulse Discharge Current450A for 1.0s

Discharge Cut-off Voltage≤11.20V

Over-Charge Protection Per Cell3.75V ± 0.03V

Over-Charge Release Per Cell3.60V ± 0.05V

Over-Charge Release MethodDischarge below release voltage

Over-discharge Protection Per Cell2.80V ± 0.05V

Over-discharge Release Per Cell3.20V ± 0.05V

Over-discharge Release MethodApply Charge/Voltage ≥12.8V

Discharge Over Current280A for 25s – 400A for 3.5s

Protection Reset Time5s Auto Release

Over Current Release MethodDisconnect Load

Battery Discharge Over TemperatureProtection to 65°C ± 5°C, Release at 50°C ± 5°C

Battery Charge Over TemperatureProtection to 55°C ± 5°C, Release at 45°C ± 5°C

Short Circuit ProtectionAuto release after 5s

Case ConstructionPowder Coated Zinc Plate

Temperature & Humidity Range≤ 30 days -20°C ̴ 60°C, 5 ̴ 75% RH, ≥ 90 days -10°C ̴ 45°C, 5 ̴ 75% RH

Nominal Voltage12.8V

Circuit ProtectionThe battery is supplied with a LiFePO4 Battery Management System BMS that can monitor and optimize each single prismatic cell during charge & discharg

Nominal Capacity200Ah

Recommended Charge Current for Maximum Life60A-120A
